VICTOR 07, Temperature Calibrator Multi-function process calibrator thermocouple calibrator,

VICTOR 07 Temperature Calibrator Multi-function process calibrator thermocouple calibrator

Products Description

VICTOR 07 Temperature Calibrator with highest accuracy is 0.05% displayed as 5 digits

1.Input measurement

★Function: DC voltage, DC current, resistance, thermocouple,thermistor, on/off

★Measurement accuracy of 0.05%, measurement display of5 digits

★Measurement rate: 2-3 times/second

★OHM and RTD can perform 2W/3W/4W measurements

★The measured temperature value and corresponding temperature signal can be switched for display

★Loop detection function: internal 24V circuit power supply and simultaneous measurement of current

★mA has a percentage display mode

2.Analog output

★Function: DC voltage, DC current, resistance, thermocouple,thermistor

★Output accuracy of 0.05%, output display of 5 digits

★Can manually increase or decrease output settings by position

★OHM excitation current has two settings: H/L

★The output temperature value and corresponding temperature signal can be switched for display

★DCl output includes active output and passive output

★mA has a percentage display mode

★When outputting DCl, manual stepping and automatic waveform output functions can be provided

3.internally provide 24V circuit power supply

4. Built in high-precision temperature sensor, capable of high-precision cold end compensation

5.DCl temperature linear conversion function

6.Allow simultaneous measurement and output of process signals, as well as simultaneous display of input measurement values and output settings

Specification
