Linshangtech LS183, Spectrum Transmission Meter,Window Tint Meter Light Transmittance LS183, 365nm UVT, 940nm IRT and VLT 47mm, Measuring Thickness Laminated Glass High Precision,

Suitable for testing the transmittance of large thickness materials

UV, IR and visible light transmission rates can be measured simultaneous

Test slot is 47mm wide, which can test large thickness of materials

Large LCD display with three different display interfaces



Description

LS183 spectrum transmission meter is primarily designed for testing the optical properties of materials such as heat-insulating coatings, single-layer glass, laminated glass, film-coated glass, PMMA, PC, and more. It can simultaneously measure ultraviolet, infrared, and visible light transmittance. The instrument features a parallel light path design, with a testing slot width of 47mm, ensuring accurate data even for thick materials. It has a large LCD display and offers a choice of three different display interfaces via a DIP switch. A support pillar is included for convenient reading when tilted.





Specifications

1. UV peak wavelength: 365nm

2. IR peak wavelength: 940nm

3. Visible light peak wavelength: 380nm-760nm (conform to CIE photopic luminosity function)

4. Resolution: 0.1%

5. Measurement accuracy: ±2%( colorless and uniform transparent materials)

6. Test sample thickness: ＜ 47mm

7. Dimension: 216 mm * 134 mm * 29 mm (L*W*H)

8. Test slot dimension: 47mm * 91 mm（W*H）

9. Weight: about 590g

10. Power supply: DC5V/1A

Parameter	Value
UV peak wavelength	365nm
IR peak wavelength	940nm
Visible light peak wavelength	380nm-760nm (conform to CIE photopic luminosity function)
Resolution	0.1%
Measurement accuracy	± 2%(colorless and uniform transparent materials)
Test sample thickness	＜ 47mm
Dimension	216 mm * 134 mm * 29 mm (L*W*H)
Test slot dimension	47mm * 91 mm（W*H）
Weight	about 590g
Power supply	DC5V/1A
