YD-3 เครื่องวัดความแข็งยา / Digital Tablet Hardness Tester with Printer Range 2-200N/0.2KG-20KG

YD-3 เครื่องวัดความแข็งยา / Digital Tablet Hardness Tester with Printer Range 2-200N/0.2KG-20KG



Brand : G&G

Model: YD-3

Type : Digital Tablet Hardness Tester with Printer



YD-3 Digital Tablet Hardness Tester with Printer Range 2-200N/0.2KG-20KG





Main Feature:

① High-precision pressure sensor to ensure the accuracy and reproducibility of the test.

② The display adopts a high-definition liquid crystal display with rich display content. Users can enjoy intelligent operation according to the screen prompts. Chinese characters and quantitative indicators are given for each operation process.

③ Optional measurement method: manual single piece/automatic continuous.

④ The system can realize automatic tablet pressing, automatic display, automatic latch, automatic reset, automatic cycle test, automatic linear error correction, automatic fault diagnosis.

⑤ Strong data processing ability, which can perform statistics, analysis, printing and display of test results. A report of the maximum, minimum, standard deviation, and range of variation of the test sample can be submitted for you.

⑥ Automatically calculate the unwinding stroke to compress your test duty time.

⑦ One-click conversion of measurement units (Newton-Kilogram).

⑧ A new type of front paper-changing micro-printer.

⑨ It is convenient and quick to measure the diameter of the tablet.







Model:  YD-3

Hardness range:  2-200N / 0.2KG-20KG

Resolution:  0.1N / 0.01Kg

Hardness measurement accuracy range:  ±0.5%

Tablet measurement diameter:  (2～40)mm

Repeated measurement error:  ±1%

Number of testing tablets in each group :  ≤100 tablets



Measuring unit

Newton (N)

Kilogram force(Kgf) (1Kgf=9.81N)



Test period ≯20S/P

Dimension(500*400*160)mm3
