เครื่องวัดความเข้มรังสี UV, LS126C UVC Light Meter Ultraviolet Sterilization Lamp UV Intensity Tester with Bluetooth Function.

Detail

 LS126C UV light meter is a professional instrument for measuring the intensity of UVC germicidal lamps, that is, the power of ultraviolet radiation energy per unit area. The UV radiometer is delivered with a 1-meter test hook in accordance with the 1-meter test requirements specified in the "WST 367-2012 Regulation of disinfection technique in healthcare settings" to ensure full compliance with the test standards. The LS126C UV radiation meter also has a Bluetooth data transmission function. After connecting with the mobile phone APP, it can monitor the intensity of the germicidal lamp in real time from a certain distance to avoid UV burns during the test.

1. The LS126C UV intensity tester is based on the detection requirements of 1 meter distance specified in the " WST 367-2012 Regulation of disinfection technique in healthcare settings ", and a 1 meter test hook is provided.

2. The UVC detector comes with a Bluetooth data transmission function. After connecting a dedicated mobile phone APP, the data can be wirelessly monitored from a certain distance to avoid being burned by ultraviolet rays when viewing the data on site.

3. LS126C UV irradiance meter has intelligent statistical data function, real-time statistics of real-time power value, maximum value, minimum value, average value in measurement data, measurement duration and test date. The real-time clock function can be used to trace the test date of historical data.

4. The UV light meter can be set to automatically shut down within 0-10 minutes. The test data will be automatically saved when the instrument is turned off, enabling unattended measurement. The NO.1 data displayed on the screen when the machine is turned on is the latest test data. The instrument can record a total of 25 sets of data.

5. The UV radiometer uses high-precision UVC filters and professional UV sensors to eliminate the influence of light intensity in the UVA and UVB bands on the data.

6. Using advanced digital probe technology, digital signal processing is done directly on the probe, the probe is not susceptible to interference and provides excellent test accuracy.

7. LS126C UV intensity detector is equipped with USB communication port and dedicated PC software. The test data can be exported to the EXCEL by computer software. The test report can also be generated and printed.



Parameters:



LS126C UV Light Meter

Spectral response  : 230nm-280nm, λp = 254nm

Measuring range  : 0 - 20000 μW / cm²

Resolution : 0.1μW / cm²

Measuring accuracy : ±10%

Power data storage interval :1s/10s/60s optional

Recording period : 10 min / 100 min / 600 min

Bluetooth transmission distance : 50 meters (open area)

Instrument size : 148mm  ×76mm  ×26mm (L*W*H)

Probe size : Diameter 46mm × thickness 16.5mm

Probe wire length:1 meter

Weight : About 300 g

Display:240*160 dot matrix LCD

Battery: 4 AAA alkaline dry batteries
